247-5232 2475232 CAT Governor Throttle Stepping Motor Caterpillar 320B 322B 325B E322B Excavator Electrical Parts
132-7806: CONTROL GP-GOVERNOR
CONTROL GP-GOVERNOR
132-7806 CONTROL GP-GOVERNOR
S/N 4DS1-UP; 5BS1-UP
PART OF 133-5364, 133-5365 CHASSIS AR
1327806 CONTROL GP-GOVERNOR Parts scheme
Parts for your 325B L EXCAVATOR:
CATERPILLAR SIS
Pos. Part No Qty Parts name Comments
1. 8T-4192 M [2] BOLT (M12X1.75X25-MM)
2. 8T-4223 [2] WASHER-HARD (13.5X25.5X3-MM THK)
3. 106-0185 [1] BRACKET AS
4. 8T-4189 M [4] BOLT (M8X1.25X20-MM)
5. 8T-4224 [8] WASHER-HARD (8.8X16X2-MM THK)
6. 4D-8123 [2] CLIP
7. 106-0070 [1] SPRING
8. 132-7802 [1] LEVER AS
9. 8T-4138 M [2] BOLT (M6X1X20-MM)
10. 9X-8256 [2] WASHER (6.6X12X2-MM THK)
11. 5C-7261 M [1] NUT (M8X1.25-THD)
12. 106-0188 [1] COVER AS
13. 247-5232 [1] ACTUATOR AS-GOVERNOR
102-8805 [1] KIT-RECEPTACLE (6-PIN)
(KIT INCLUDES RECEPTACLE AS & WEDGE)
9W-0852 [6] PIN-CONNECTOR (14-GA TO 16-GA)
157-3160 [1] JOINT
14. 099-3649 M [2] BOLT (M8X1.25X40-MM)
319-4243 AFY [1] CABLE GP-GOVERNOR CONTROL
(REFER TO REHS3989 FIELD REPAIR OF GOVERNOR MOTOR CABLES)
A NOT PART OF THIS GROUP
F NOT SHOWN
M METRIC PART
Y SEPARATE ILLUSTRATION
